一般客戶有比較大產品需要做小批量生產可產品數量都沒有達到上萬個，這時候客戶為了節約成本就會選用低壓灌注的方式來制作，下面來講講低壓灌注模型工作原理用途等內容吧

Generally, customers have relatively large products that need to be produced in small batches, but the number of products does not reach tens of thousands. At this time, customers will choose the low-pressure injection method to make them in order to save costs. Let's talk about the working principle and purpose of the low-pressure injection model

低壓灌注是一種快速模具制品生產的新工藝，它相對注塑來說成本較低，由于它的產品都是 整體成型出來的，所以低壓灌注生產出來的產品具有縮水和變形較小，有效率高、生產周期短、過程簡單、成本低的優點，制作的產品強度也高。在當下的行業情況下來說客戶的需求是越來越大。

Low pressure pouring is a new process for the production of rapid tooling products. Its cost is lower than that of injection molding. Because its products are integrally molded, the products produced by low pressure pouring have the advantages of small shrinkage and deformation, high efficiency, short production cycle, simple process, low cost, and high product strength. In the current industry situation, the demand of customers is growing.

低壓灌注成型的工作原理：將預先配制好的多組份聚氨酯材料經計量泵以一定的配比送入混合頭經混合后，在低壓環境下注入快速模具內，通過材料的聚合、交聯、固化等化學和物理過程形成制品，注入量由泵的單位吐出量和注射時間來控制。

Working principle of low-pressure injection molding: the pre prepared multi-component polyurethane material is sent to the mixing head through the metering pump in a certain proportion. After mixing, it is injected into the rapid tooling under low-pressure environment, and the product is formed through chemical and physical processes such as polymerization, crosslinking and curing of the material. The injection amount is controlled by the unit discharge of the pump and the injection time.

低壓灌注的用途：山東快速成型廠家認為其適用于產品開發過程中的小批量試制，以及小批量生產的、結構較簡單的覆蓋件和大型厚壁及不均勻壁厚制品的生產。

Application of low-pressure pouring: Shandong rapid prototyping manufacturers believe that it is suitable for small batch trial production in the process of product development, as well as the production of small batch production, simple structure panels and large thick wall and uneven wall thickness products.

低壓灌注適用模具有：樹脂模具，ABS模具，鋁合金模具

The applicable molds for low-pressure pouring are: resin mold, ABS mold, aluminum alloy mold

低壓灌注澆注材料為：雙組份聚氨酯材料

Low pressure pouring material: two component polyurethane material

低壓灌注物理性能：類似PP/ABS，產品具有耐老化，抗沖擊力強，吻合度高，易裝卸等特點。

Physical properties of low-pressure perfusion: similar to pp/abs, the product has the characteristics of aging resistance, strong impact resistance, high coincidence, easy loading and unloading, etc.

標準復制精度：±0.20mm/100mm。

Standard copy accuracy: ± 0.20mm/100mm.

澆注樣件厚度：很佳澆注厚度4~6mm，很大澆注厚度10mm。

Thickness of pouring sample: the best pouring thickness is 4~6mm, and the great pouring thickness is 10mm.

很大澆注工件：2000mmX1200mmX1000mm，10KG。

Large pouring workpiece: 2000mmx1200mmx1000mm, 10kg.

低壓灌注應用范圍：汽車模型及配件、醫療設備外殼、玩具類、數碼產品、家用電子、健身器材、等小批量的生產。

Application scope of low-pressure perfusion: small batch production of automobile models and accessories, medical equipment shells, toys, digital products, household electronics, fitness equipment, etc.

低壓灌注模型工作原理用途等內容的了解就到這里了，如果您的需求正好與該產品相關，您不妨先關注我們網站http://www.xtgs.com.cn聯系客服人員咨詢了解。

That's all for the understanding of the working principle and purpose of the low-pressure perfusion model. If your demand is just related to this product, you might as well pay attention to our website first http://www.xtgs.com.cn Contact customer service personnel for consultation.
