在塑膠產品的生產過程中，為了提高生產速率，盡量縮短產品的開發周期，通常會直接采用模具進行塑膠產品的生產。目前，現有的模具仍存在一定的不足之處，使用過程中，注塑完成后的模具通常溫度較高，無法立即將模具中的產品取出，進而導致生產效率下降，因此，亟需設計一種用于塑膠產品山東快速成型的模具來解決上述問題。

In the production process of plastic products, in order to improve the production rate and shorten the product development cycle as much as possible, molds are usually directly used for the production of plastic products. At present, there are still some deficiencies in the existing molds. In the process of use, the mold after injection molding is usually high in temperature, and the products in the mold can not be taken out immediately, resulting in a decline in production efficiency. Therefore, it is urgent to design a mold for rapid molding of plastic products in Shandong to solve the above problems.

本實用新型的目的是為了解決現有技術中存在的缺陷，而提出的一種用于塑膠產品快速成型的模具。為了實現上述目的，本實用新型采用了如下技術方案：

The purpose of the utility model is to solve the defects in the prior art, and to propose a mold for rapid molding of plastic products. In order to achieve the above purposes, the utility model adopts the following technical schemes:

一種用于塑膠產品快速成型的模具，包括座體，所述座體的外壁設置有下模具，所述下模具的外側設置有冷卻筒，且冷卻筒中設置有螺旋腔，所述座體的外壁設置有制冷箱，且制冷箱和螺旋腔之間通過回流管相連通，所述座體的外壁還設置有液泵，且液泵的導液端通過導液管和螺旋腔相連通，所述液泵的抽液端通過抽液管和制冷箱相連通，所述座體的外壁還設置有伸縮件一，且伸縮件一的伸縮端設置有安裝板，所述安裝板的外壁設置有限位桿，且限位桿的端部設置有擋片，所述限位桿的外壁套接有彈性件，且限位桿的外壁滑動設置有壓板，所述壓板的外壁設置有上模具，且上模具設置于冷卻筒中。

A mold for rapid prototyping of plastic products, including a seat body, the outer wall of the seat body is provided with a lower mold, the outer side of the lower mold is provided with a cooling cylinder, and the cooling cylinder is provided with a spiral cavity, the outer wall of the seat body is provided with a cooling box, and the cooling box and the spiral cavity are connected through a return pipe, the outer wall of the seat body is also provided with a liquid pump, and the liquid guide end of the liquid pump is connected with the spiral cavity through a liquid guide pipe, The liquid extraction end of the liquid pump is connected with the refrigeration box through the liquid extraction pipe, the outer wall of the seat body is also provided with an expansion piece, and the expansion end of the expansion piece is provided with a mounting plate, the outer wall of the installation plate is provided with a limit bar, and the end of the limit bar is provided with a stopper, the outer wall of the limit bar is sleeved with an elastic piece, and the outer wall of the limit bar is sliding with a pressing plate, and the outer wall of the pressing plate is provided with an upper mold, The upper mold is set in the cooling cylinder.

與現有技術相比，本實用新型的有益效果是：

Compared with the prior art, the utility model has the following beneficial effects:

本實用新型提供的一種用于塑膠產品快速成型的模具，通過伸縮件一可以帶動安裝板移動，使得壓板上的上模具可以進入冷卻筒中與下模具相接觸，同時壓板會促使限位桿上的彈性件被壓縮，使得上模具可以和下模具緊密貼合，然后便可以通過注塑機構將物料注塑模具和下模具之間的縫隙中，當注塑完成后，可以通過液泵將制冷箱中的冷卻液導入冷卻筒內的螺旋腔中，然后再通過回流管流入制冷箱中重新進行制冷，使得冷卻液可以不斷循環使用，實現對模具的有效散熱，使得模具內的產品可以快速成型，使用效果更佳。

The utility model provides a mold for rapid molding of plastic products, which can drive the installation plate to move through the expansion part one, so that the upper mold on the pressure plate can enter the cooling cylinder and contact with the lower mold, and the pressure plate will cause the elastic part on the limit bar to be compressed, so that the upper mold can closely fit with the lower mold, and then the material can be injected into the gap between the upper mold and the lower mold through the injection mechanism, After the injection molding is completed, the cooling liquid in the cooling box can be led into the spiral cavity in the cooling cylinder through the liquid pump, and then flow into the cooling box through the return pipe for refrigeration, so that the cooling liquid can be recycled continuously, and the effective heat dissipation of the mold can be achieved, so that the products in the mold can be rapidly molded, and the use effect is better.

為了使本實用新型的目的、技術方案及優點更加清楚明白，以下結合附圖及實施例，對本實用新型進行進一步詳細說明。應當理解，此處所描述的具體實施例僅僅用以解釋本實用新型，并不用于限定本實用新型。更多相關內容可以隨時來我們網站http://www.xtgs.com.cn進行咨詢！

In order to make the purpose, technical scheme and advantages of the utility model more clear, the utility model is further described in detail with the attached drawings and embodiments. It should be understood that the specific embodiments described here are only used to explain the utility model, not to limit the utility model. For more relevant content, please visit our website at any time http://www.xtgs.com.cn Consult!
