其實這一步驟在整個流程比重中占有較大的一部分，一個手工師傅的技藝精不精湛也直接影響到濟南手板裝配，及手板外觀問題，包括手板一些小細節的把握！

In fact, this step accounts for a large part of the whole process. The craftsmanship of a craftsman has a direct impact on the assembly and appearance of the Jinan prototype, including the grasp of some small details of the prototype!

1.毛邊：CNC加工下來后，手板件周圍是有很多毛刺的，這只需要用三角刀按周邊輕輕繞一圈就能處理干凈了，當然尼龍等堅韌材料毛刺很難處理，非常影響外觀，有外觀要求手板一般不建議用這種材料。

1. Remove burrs: after CNC processing, there are many burrs around the hand board, which can be cleaned by gently winding around the periphery with a triangular knife. Of course, the burrs of nylon and other tough materials are difficult to handle, which greatly affects the appearance. It is generally not recommended to use this material for hand boards with appearance requirements.

2.核對尺寸：手工是對手板尺寸的初次檢查，若有尺寸不合格產品也可直接向CNC反應重做，這樣做的好處在于可以迅速反應節省成本不會浪費太多時間，若產品已經做好才發現尺寸問題那不僅增加成本同時也耽誤了交期。

2. Size check: Handwork is the initial inspection of the size of the hand board. If there are unqualified products, they can also be directly reported to the CNC for rework. The advantage of this is that it can quickly respond and save costs without wasting too much time. If the product has been well prepared, it will not only increase the cost but also delay the delivery.

3.粘接：有些尺寸過大超出機臺加工范圍或結構復雜難以加工到位的，手板廠一般選擇拆件做，手工這一步需要把這些拆件按圖紙粘回原樣，要注意的是一定要粘接平整無縫，不然很影響手板尺寸，外觀及裝配！對于這一點，相信很多手工師傅還是非常有經驗的

3. Bonding: For those whose size is too large to be processed on the machine or whose structure is complex and difficult to be processed in place, the prototype factory usually chooses to disassemble them. In the manual step, these disassembled parts need to be glued back to the original shape according to the drawings. Note that the bonding must be smooth and seamless, otherwise the size, appearance and assembly of the prototype will be affected! For this, I believe that many craftsmen are very experienced

4.裝配：通常來說裝配分為兩步，初步為CNC拿過來后的裝配叫配白板：手工按照圖紙對產品特征及裝配位加以精修，使產品組裝通順，更加精致！這一過程也能及時發現設計上的缺陷，并做到隨時跟客戶溝通！二步為手板噴油完成后手工再裝機：其實到這里手工只要對手板各部件進行再組合，一款漂亮的手板模型也基本完成。

4. Assembly: Generally speaking, assembly is divided into two steps. The assembly after CNC is taken is called white board: the product features and assembly positions are refined manually according to the drawings to make the product assembly smooth and more refined! This process can also find design defects in time and communicate with customers at any time! The second step is to manually re install the machine after the completion of hand injection: in fact, a beautiful hand model is basically completed as long as the hand parts are manually re assembled here.

手工其實是后處理工藝的一個步驟，主要包含毛邊、核對尺寸、粘接、裝配。以上就是講解的詳細內容了，您對此有什么了解可以隨時來我們網站http://www.xtgs.com.cn進行咨詢！

Handwork is actually a step of post-treatment process, mainly including removing burrs, checking dimensions, bonding and assembly. The above is the detailed explanation. You can come to our website at any time if you have any information about it http://www.xtgs.com.cn Consult!
