在制作手板模型以前，手板模型的設定對提升手板模型的質地十分關鍵。實際上，手板模型必須考慮到許多要素，如手板模型原材料的選擇.手板模型構造的易用性和系數.手板模型零件的可工藝性能和手板模型維護保養的便捷性，這種都需要在設計方案手板模型之初盡量地考慮到。那，制作手板模型前必須留意有哪些問題呢？

Before making a prototype, the setting of the prototype is crucial for improving the texture of the prototype. In fact, many factors must be taken into account in the prototype model, such as the selection of raw materials for the prototype model, the ease of use and Factor of safety of the prototype model construction, the processability of the prototype model parts, and the convenience of the prototype model maintenance, which all need to be considered as far as possible at the beginning of the prototype design scheme. So, what are the issues that you must pay attention to before making a prototype?

濟南手板模型原材料的選擇：

Selection of raw materials for Jinan hand board models:

手板模型原材料的選擇不但要達到顧客對產品品質的規定，還需要考慮到原料的費用和設計方案周期時間的抗壓強度。與此同時要依據手板模型的種類.工作方式.加工速率.關鍵無效方式等原因開展選擇。冷沖模的具體常見故障方式是刀口損壞，因而必須選擇表層強度高、耐磨性能好的原材料；

The selection of raw materials for the prototype should not only meet the customer's requirements for product quality, but also consider the cost of raw materials and the compressive strength of the design cycle time. At the same time, the selection should be based on the types, working methods, processing rates, key ineffective methods, and other reasons of the prototype model. The specific common failure mode of cold stamping dies is blade damage, so it is necessary to choose raw materials with high surface strength and good wear resistance;

冷沖模關鍵承擔規律性載荷，非常容易導致表層疲憊裂痕和脫落，因而應選擇表層驕縱好的原材料；拉伸模具應選擇摩擦阻力尤其低的原材料；因為循環系統內應力的危害，鋁壓鑄不可選擇熱疲憊性強的原材料。

Cold stamping dies bear regular loads, which can easily lead to surface fatigue, cracks, and detachment. Therefore, raw materials with good surface tolerance should be selected; The stretching mold should choose raw materials with particularly low friction resistance; Due to the harm of stress in the circulating system, aluminum die-casting cannot choose raw materials with strong thermal fatigue.

手板模型制作加工常見問題：

Common problems in the production and processing of hand board models:

制訂手板模型加工工藝線路可依據產品工件必須分多次加工。加工手板模型外型內腔，切削標準，隨后旋轉180度夾持，加工外表層和功能鍵顯示屏部位。如先加工外表層，再加工內腔，難以定位工裝夾具開展二次加工。

The development of a prototype processing process can be based on the fact that the product workpiece must be processed multiple times. Process the outer and inner cavities of the hand board model, cut to standard, then rotate 180 degrees to clamp, and process the outer layer and function key display screen. If the outer layer is processed first and then the inner cavity is processed, it is difficult to locate the fixture for secondary processing.

假如手巖面厚僅有1.5mm，加工外表層時非常容易形變若在加工后的凹模中添加填充料開展支撐點。那樣可以防止在添充熟石膏以前加工埋孔，不然難以將制成品和填充料分離。先修補剪修斜面，遮蓋表層埋孔部位，開展正臉加工，槽進行埋孔加工，防止精雕軟件波動受阻.切削速度不勻稱等狀況。

If the thickness of the hand rock surface is only 1.5mm, it is very easy to deform when processing the outer layer. If filling material is added to the processed concave mold to support the point. That can prevent processing buried holes before adding gypsum, otherwise it is difficult to separate the finished product from the filling material. Firstly, repair and trim the inclined surface, cover the surface buried hole area, carry out front face processing, and perform buried hole processing on the groove to prevent the fluctuation of the precision carving software from being hindered and the cutting speed from being uneven.
