在產品設計和產品研發的早期階段，手板模型的應用不適合批量生產和加工。如果模型開放，風險很大。因此，越來越多的公司選擇做手板模型來檢查外觀和結構，并提前搶占市場。下面山東快速成型廠家來講講鋁合金手板的制作工藝及避免大批量生產風險相關內容。

In the early stage of product design and product development, the application of prototype model is not suitable for mass production and processing. If the model is open, the risk is great. Therefore, more and more companies choose to make prototype models to check the appearance and structure, and seize the market in advance. The following is about the manufacturing process of aluminum alloy hand plate and the related content of avoiding the risk of mass production.

鋁合金手板的制作工藝

Manufacturing technology of aluminum alloy hand plate

1、CNC電腦經過CNC加工設備根據程序設定的路徑，在產品的原材料的基礎上進行改動，得到鋁合金手板模型的雛形。

1. The CNC computer changes the raw materials of the product through the CNC processing equipment according to the path set by the program, and obtains the rudiment of the aluminum alloy hand model.

2、手工處理.在鋁合金手板模型的雛形出來之后，樣件的外觀會有一些毛刺以及邊角多余的部分，工作人員應該用砂紙磨平，使得鋁合金手板模型的外觀變得潤滑精美。

2. Manual processing After the prototype of the aluminum alloy hand model is formed, the appearance of the sample will have some burrs and redundant edges and corners. The staff should use sandpaper to smooth it, so that the appearance of the aluminum alloy hand model becomes smooth and beautiful.

3、鐳雕，便是用激光技能打掉樣件外觀的油漆，使樣件的一部分方位透光.

3. Laser engraving is to use laser technology to remove the paint on the appearance of the sample and make part of the sample transparent

4、氧化，即陽極處理，是行使電解的效果，由于處理往后形成的氧化的耐蝕性差、硬度低，因而工藝過程中很少運用。

4. Oxidation, that is, anodic treatment, is the effect of electrolysis. Since the oxidation formed after treatment has poor corrosion resistance and low hardness, it is rarely used in the process.

5、拉絲，就是在鋁合金的外觀拉出一條條細痕，如許的處理會使樣件的質感更好。

5. Wire drawing is to pull out fine marks on the appearance of aluminum alloy. Such treatment will make the texture of the sample better.

鋁合金手板制作避免大批量生產風險

Aluminum alloy hand plate production to avoid the risk of mass production

手板模型作為前期的關鍵，它對產品的規劃定位、本錢控制、出產出售和質量檢測等工序起著重要的效果，假如你要研發一款新的的話，就得先要做少數手板來進行檢驗，承認無誤后，再進行批量出產。

As the key of the early stage, the prototype model plays an important role in the planning and positioning of the product, cost control, production and sales, quality inspection and other processes. If you want to develop a new model, you must first do a few prototypes for inspection, and then carry out batch production after admitting that there is no error.

此面板手板的原料是abs，選用的是cnc加工的辦法，其大致過程根本是這樣的，先經過CNC加工將面板手板的雛形鑼出來，然后用砂紙將剩余的毛刺磨掉，噴上客戶要求的色彩，接著在烤爐里邊烘烤一段時間，經過cnc加工出來的面板手板，不僅精度高，而且表面光澤鮮艷，比產品的原型愈加精巧。

The raw material of this panel is ABS, and the method of CNC processing is adopted. The basic process is as follows: first, the prototype of the panel is processed by CNC, and then the remaining burr is abraded with sandpaper, sprayed with the color required by the customer, and then baked in the oven for a period of time. The panel processed by CNC is not only high in accuracy, but also bright in surface luster, which is more exquisite than the prototype of the product.

經過手板制造，可以使某些規劃完結但不完善的產品進行及時的批改，以防一旦投入大規模大批量出產后，才發現不美觀甚無法運用導致全部作廢！更多關于這方面的注意事項您可以來我們網站http://www.xtgs.com.cn咨詢了解。

After the prototype manufacturing, some products that have completed the planning but are not perfect can be timely corrected, so as to prevent them from being found to be unsightly or even unusable once they are put into large-scale mass production! For more information, please visit our website http://www.xtgs.com.cn Consultation and understanding.
